Specifications
Technical details
Board Size (W x L)
190mm x 1900mm 120mm x 600mm 190mm x 1900mm 240mm x 2200mm 220mm x 2200mm
Thickness
12 mm 14mm 14 mm 14 mm 20 mm
Veneer Thick ness
2mm 3mm 3mm 2mm 6mm
Pack Size
2.527m 2 1.152m2 2.166m2 2.112m2 1.936m2
Finish
Satin Satin Satin Satin Satin
Boards per Pack
7 (25% nested) 16 (8A & 8B) 6 (25% nested) 4 (25% nested) 4 (25% nested)
Texture
Brushed Brushed Brushed Brushed Brushed
Grade & Colour Variation
ABCD AB ABC ABCD ABCD
Profile
T & G T & G Click/5G – End Click T & G T & G
Stability/Density
750kg/m 3 750kg/m3 750kg/m 3 750kg/m 3 750kg/m 3
Construction
Multilayer Ply Core Multilayer Ply Core Multilayer Ply Core Multilayer Ply Core Multilayer Ply Core
Raft Size (W x L)
Floating 8m x 12m / Direct Stick 10m x 20m Floating 8m x 12m / Direct Stick 10m x 20m Floating 8m x 12m / Direct Stick 10m x 20m Floating 8m x 12m / Direct Stick 10m x 20m Floating 8m x 12m / Direct Stick 10m x 20m
Installation Method
Floating, Direct Stick Floating, Direct Stick Floating, Direct Stick Floating, Direct Stick Floating, Direct Stick
Perimeter Gap & Coverage -min
7mm & 7mm 7mm & 7mm 7mm & 7mm 7mm & 7mm 7mm & 7mm
Floor Level over 2mm
4 mm 4 mm 4 mm 4 mm 4 mm
Moisture Protection
Standard 8 hours Standard 8 hours Standard 8 hours Standard 8 hours Standard 8 hours
Direct UV and Heat Protection
Standard 2 Hours Standard 2 hours Standard 2 Hours Standard 2 Hours Standard 2 Hours
Under Floor Heating
Yes 21°C- 27°C Yes 21°C- 27°C Yes 21°C- 27°C Yes 21°C- 27°C Yes 21°C- 27°C
Climate & Environment Control
18°C – 26°C | RH 40%-60% 18°C – 26°C | RH 40%-60% 18°C – 26°C | RH 40%-60% 18°C – 26°C | RH 40%-60% 18°C – 26°C | RH 40%-60%
Wear Resistance
High Residential 7 Layers UV-Cured Lacquer High Residential 7 Layers UV-Cured Lacquer High Residential 7 Layers UV-Cured Lacquer High Residential 7 Layers UV-Cured Lacquer High Residential 7 Layers UV-Cured Lacquer
Scratch Resistance
Standard Standard Standard Standard Standard
Fire Safe
Yes Yes Yes Yes Yes
Slip Rated
P2 P3 P3 P3 P2
Emission Compliant
E0 E0 E0 E0 E0
Acoustic Compliant
Yes Yes Yes Yes Yes
Residential Warranty*
30 years 30 years 30 years 30 years 30 years
Medium Commercial Warranty*
5 years 5 years 5 years 5 years 5 years
Length
1900mm
Thickness
12mm
Species
European
